SealMaster SP 300 - Parts List

40
SQUEEGEE SP300 DUAL/SPRAY
APPLIES TO: SP 300 DUAL
PARTS LIST
ITEM #
PART#
QTY.
DESCRIPTION
103
P966A078
1
SWITCH MOUNT COVER
104
P966A079
1
MOUNTING PLATE - SWITCH
105
P442A003
1
SNAP SWITCH
106
P966A080
1
LEVER
107
P966A081
1
SHIFTING ARM
108
P966A082
2
CHAMBER DIAPHRAGM
109
P966A083
2
GASKET - CHAMBER DIAPHRAGM
110
P966A084
2
ELBOW - CHAMBER DIAPHRAGM
111
P966A085
2
PLATE ASSEMBLY OUTER
112
P966A074
2
DIAPHRAGM – NEOPRENE
113
P966A086
2
PLATE – INNER
114
P966A087
1
CHAMBER INNER – RIGHT
115
P966A088
1
CHAMBER INNER – LEFT
116
P694A001
1
ELECTRIC COIL 12V
117
P600A007
1
HYDRAULIC CYLINDER
118
P966A066
1
DISCHARGE PORTING FLANGE
119
P966A068
4
GASKET – MANIFOLD
120
P966A065
4
CHECK BALL – NEOPRENE
121
P966A072
2
SEAT ASSEMBLY
122
P966A067
1
SUCTION PORTING FLANGE
123
P966A073
2
FLANGE THREADED
124
P966A070
2
O RING
125
P966A069
1
MANIFOLD
126
P966A071
2
SEALING RING
127
P1014A034
4
HEX HEAD SCREW 1/2-13” X 1-3/4”
128
P1018A005
4
SPLIT LOCK WASHER 1/2"
129
P1021A002
12
LOCK NUT 1/2-13"
130
P1020A005
8
HEX NUT 1/2-13"
131
P1025A001
8
EXTERNAL TOOTH FLAT WASHER 1/2"
132
P1014A021
20
HEX HEAD SCREW 3/8-16” X 2”
133
P1017A003
40
FLAT WASHER 3/8"
134
P1021A001
20
NYLON INSERT LOCKNUT 3/8-16"
135
P1021A008
4
HEX NUT 3/8-16"
136
P1036A020
4
SOCKET HEAD CAP SCREW 1/4”-20 X 3/4”
137
P1021A006
4
NYLON INSERT LOCKNUT 1/4-20"
138
P1014A011
2
HEAD HEX SCREW 5/16-18” X 1-1/2”
139
P1021A005
2
LOCK NUT 5/16-18"
140
P1026A005
4
MACHINE SCREW 10-32 X 1/2"
141
P1017A005
4
FLAT WASHER 1/2"
