Seaory S22 Desktop Dual-sided Card Printer
Excellent quality, Perfect service www.seaory.com 6 / 53
Main function description：
Bottom cover: Place to install magnetic stripe card and chip card
encoding module.
3.6 Internal structures
Main function description：
A Air fan: absorb and release the print head’s heat when it works.
B Print head: need regular cleaning.
C Ribbon cartridge: accessory to install ribbon.
D Ribbon pickup roller: recycle used ribbon.
E Cleaning roller: sticky card surface dust, improve the printing
effect.
A
B
C
D
E
F
G
Card printer bar code: Information needed when you need technical services from us.
