Sears Elite 665.12779K310 - Removing Lower Spray Arm

COMPONENT ACCESS
Kenmore Elite 2013 Stainless Steel Tall Tub Dishwasher
n
3-13
3. Li o, see gure 3.
3803 :$6+$50 $1' 02725 3$576

 3DUW 1R : 5HY $
To remove the lower spray arm:
1. Lower spray arm nut locaon, see gure 1.
2. Rotate the lower spray arm nut ¼ turn counter clockwise
to remove the spray arm, see gure 2.
Figure 1
Figure 2
Lower Spray Arm Assembly
Removing Lower Spray Arm
Figure 3
Water Jets
Nut
