Kenmore Elite 2013 Stainless Steel Tall Tub Dishwasher
COMPONENT ACCESS
1. Use a pair of diagonal pliers to cut o the hose clamps,
see gures 1 and 2.
Figure 1
Figure 2
Wash Motor Replacement
Steps for Removing Old Wash Motor
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
connued next page . . .
2. Remove old clamps, see gure 3.
Figure 3
3. Remove motor from seal, see gure 4.
Figure 4
4
