COMPONENT ACCESS
Kenmore Elite 2013 Stainless Steel Tall Tub Dishwasher
n
3-27
5. Remove seal, see gure 6.
Figure 6
4. Pry up on old seal, see gure 5.
Figure 5
Steps for Removing Old Wash Motor (continued)
Motor and Sump Assembly
Isolator
Latch &
Screw (3)
Sump and Seal
Hose Assembly
(includes 2 clamps)
Grommet
Wash Motor
5
6
