© 2012 SeaStar Solutions Optimus 360 User’s Manual, Rev. C
6-1
The joystick is the primary user interface for the Joystick Control System.
It offers the ultimate control of the vessel for docking and maneuvering
at slow speeds and is especially useful in confined or difficult
circumstances. It is quite intuitive to use as the boat follows the actions
of the handle. This section of the manual gives a detailed description
of all of its capabilities and how to get the maximum benefit from this
powerful feature. The Joystick 360 Quick Reference Guide, provided
with the system, gives summary and reminder information on its
operation and should be kept on the vessel at all times.
The joystick is spring loaded so it always returns to its center position.
When the joystick is active and in the center position, the engines
are in neutral and the throttles are at idle.
The joystick Take Command button will make the joystick active and
shut off the control head when it is pushed. The shift and throttle
controls must be in neutral to engage the joystick. When the joystick
is active, the Take Command light will be solid blue and the control
head lights will turn off.
While the joystick is active the turning resistance of the steering
wheel will increase to remind the user that it is disengaged.
The Boost button increases the engine RPM when pressed. It may
be activated any time the joystick is active.
Note: The A and C buttons are reserved for future use and not active
at this time.
6.0 JOYSTICK OPERATION
While the joystick is active the turning resistance of the steering
wheel will increase to remind the user that it is disengaged.
NOTICE
