© 2012 SeaStar Solutions Optimus 360 User’s Manual, Rev. C
8-1
The detent pressure and drag can be adjusted using the adjusting
screws on the front surface of the control head.
8 .0
FIRST TIME USE
Before starting the engines for the first time, take a moment to
familiarize yourself with the shift and throttle controls. With the engines
not running and the control system turned off, move the control levers
over the full range until you are familiar with the feel. Note that the
detent pressure and drag can be adjusted using the adjusting screw
on the front surface of the control head. The top screw sets the detent
pressure; the lower screw sets the drag.
8.1 Control Head Adjustments
Figure 8-1. Control Head lever positions.
NOTICE
Adjusting
Screws
