261Technical specifications
Technical specifications
Checking fluid levels
Fig. 214 Diagram for the location of the various elements.
From time to time, the levels of the different fluids in the vehicle must be
checked. Never fill with incorrect fluids, otherwise serious damage to the
engine may be caused.
Coolant expansion tank
Windscreen washer reservoir
Engine oil filler cap
Engine oil dipstick
Brake fluid reservoir
Vehicle battery (underneath the cover)
The checking and refilling of service fluids are carried out on the compo-
nents mentioned above. These operations are described in the
⇒
page 204.
1
2
3
4
5
6
Overview
You will find further explanations, instructions and restrictions on the tech-
nical specifications as of ⇒ page 257.
