44 Cockpit
Note
Some of the items of equipment listed here are fitted only on certain model
versions or are optional extras.
Instruments
Instrument overview
Fig. 34 Detailed view of the dash panel: instrument panel.
Fuel gauge ⇒ page 44
Multifunction display ⇒ page 47
Engine coolant temperature display ⇒ page 46 or the natural gas lev-
el indicator in vehicles with natural gas engine (LPG) ⇒ page 45
Rev counter ⇒ page 46
1
2
3
4
Time adjustment button / trip recorder reset button ⇒ page 47
Speedometer ⇒ page 47
Fuel gauge and reserve indicator
Fig. 35 Instrument pan-
el: fuel gauge
The fuel tank has a capacity of approx. 55 litres.
When the needle reaches the reserve area ⇒ Fig. 35 (arrow), the warning
lamp will light up and an audible warning will sound reminding the driver to
refuel. At this point there are still 7 litres of fuel in the tank.
The following text appears in the dash panel display
1)
:
PLEASE REFUEL [XXX]
5
6
1)
Depending on the version of the model.
