Technical data
››› Fig. 232, ››› Fig. 233 2WD 4WD
A Front projection (mm) 868 868
B Rear projection (mm) 857 865
C Wheelbase (mm) 2,638 2,630
D Length (mm) 4,363
E Front
a)
track (mm) 1,576 1,572
F Back
a)
track (mm) 1,541 1,544
G Width (mm) 1,841
H Height at kerb weight (mm)
1,601
b)
1,615
c)
1,611
b)
1,625
c)
I Ground clearance between the axles (mm) 176 189
J Front projection angle limited by the bumper maximum 19.4° maximum 20.6°
K Rear projection angle limited by the bumper maximum 27.9° maximum 25.5°
Turning radius (m) 10.8
a)
This data will change depending on the type of wheel rim.
b)
Distance to the roof.
c)
Dimension to the roof bars.
