Emergencies
Fig. 107 Fog light: remove the bulb holder
Follow the steps indicated:
R
emo
ve the screw ››› Fig. 106
1
A fr
om
the f
og light grille using a screwdriver
and extract the grille.
Remove the screws (3x) ››› Fig. 106
2
B
and e
xtr
act the fog light.
Remove the metal clip situated on the
upper part of the fog light by pulling to-
wards the exterior of the vehicle
3
Remove connector
›
›
›
Fig. 107
1
from
the b
u
lb.
Turn the bulb holder
›››
Fig. 107
2
anti-
c
loc
kwise and pull.
Remove the bulb by pressing on the
bulb holder and turning it anticlockwise
at the same time.
Installation involves all of the above
steps in reverse sequence.
Check that the bulb works properly.
1.
2.
3.
4.
5.
6.
7.
8.
Note
Due to the difficulty of accessing fog light
bu
lbs, have them replaced at a Technical
Service or specialised workshop.
Change the rear bulbs
Over
view of tail lights
Tail lights on side panel
Turn signal PY21W NA LL
Side light and brake light P21W LL
Tail lights on the rear lid
Left side
Side lights P21W LL
Fog light/side light P21W LL
Reverse light W16W
Right side
Side lights 2 x P21W LL
Reverse light W16W
The table corresponds to a right-hand traffic
v
ehic
le. The position of lights may vary ac-
cording to the country.
Rear bulbs (in the side panel)
Fig. 108 Luggage compartment: access to the
bo
lt
securing the tail light unit.
Fig. 109 Retaining tabs on reverse side of tail
light
.
Follow the steps indicated:
Chec
k
which of the bulbs is defective.
Open the rear lid.
1.
2.
96
