Fuses and bulbs
Fig. 105 In the engine compartment: main
be
am he
adlight bulb
2
and turn signal bulb
3
.
Follow the steps indicated:
M
ain be
am headlight bulb
Raise the bonnet.
Move the loop ››› Fig. 104
1
in the di-
r
ection of
the arrow and remove the cov-
er.
Slide connector ››› Fig. 105
2
to the left
or right
and p
ull.
Remove the bulb by disconnecting the
connector.
Installation involves all of the above
steps in reverse sequence.
1.
2.
3.
4.
5.
Turn signal bulb
Raise the bonnet.
Move the loop ››› Fig. 104
1
in the di-
r
ection of
the arrow and remove the cov-
er.
Turn the bulb holder ››› Fig. 105
3
anti-
c
loc
kwise and pull.
Remove the bulb by pressing on the
bulb holder and turning it anticlockwise
at the same time.
Installation involves all of the above
steps in reverse sequence.
1.
2.
3.
4.
5.
Front fog light bulb*
Fig. 106 Fog light: extracting the grille.
»
