The essentials
Weight group Size class
Electrical
equipment
Vehicle Isofix positions
Front passenger seat
Rear side seat Rear central seat
airbag on airbag off
IUF: Suitable for forward-facing ISOFIX universal child restraint systems approved for use in this mass group.
IL
: Suitabl
e for certain ISOFIX child restraint systems (CRSs) listed in the attached list. This relates to ISOFIX CRSs that can be for the specific vehicle, restricted or semi-
universal categories.
: ISOFIX position not suitable for ISOFIX child restraint systems for this weight group or size class.
››› in Safety instructions on
page 83
Securing child seats with the “ISOFIX/i-Size” ISOFIX System
Fig. 39 ISOFIX/iSize securing rings.
You are obliged to follow the seat manufac-
t
ur
er
's instructions.
●
Press the child seat onto the “ISOFIX” re-
taining rings ››› Fig. 39 until the child seat is
heard to engage securely. If the child seat is
equipped with Top Tether* anchor points, se-
cure it to the correspondent ring ››› Fig. 40.
Observe the manufacturer's instructions.
●
Pull on both sides of the child seat to ensure
that it is properly anchored.
Child seats with the “ISOFIX” and Top Tether*
attachment system are available from Tech-
nical Services.
30
