Seca 222 User Manual

8 •
3.2 Marking on the device and on the rating plate
5
Lock
• Locks head slide at top of upper telescopic element for
measurement in measuring range 2
• Releases head slide for measurement on lower teles-
copic element (measuring range 1)
6
Head slide
• Locked at top of upper telescopic element
• To be released for measurement on lower telescopic
element (measuring range 1)
7
Read-off line 1 (red)
Reference when head slide is positioned on lower teles-
copic element to measure persons smaller than
130.5 cm (51.4 inch)
8
Read-off line 2 (red)
• Reference when measuring persons taller than
130.5 cm (51.4 inch)
• Results to be read off at upper telescopic element
(here: 155.5 cm)
9
Spacer washer
• A maximum of 5 per screw to allow the measuring rod
to be attached to a wall precisely vertically
• Protruding walls or attachments (e.g. skirting boards or
cable ducts) can be compensated
10
Fixing hole
The fixing screw of the measuring rod is inserted in this
hole
11
Spacer washer
A maximum of 5 per screw to support the heel stop
against the wall
12
Heel stop
Helps the patient to assume the correct postion for mea-
surement
No. Element Function
Text/Symbol Meaning
Model Model number
xx/xx Batch number, engraved on back of device
Observe user manual
Device complies with EC standards and directives
• 0123: Notified body medical products:
TÜV SÜD Product Service
0123
