Sedecal SHF-415 - Page 31

HF Series Generators -- RAD Console
Operation
OM- 0279R1
23
Table 3-1
APR Matrix (English)
A
P
R
M
A
T
R
I
X
ANATOMICAL VIEWS
APR MATRIX
View-1 View-2 View-3 View-4 View-5 View-6 View-7 View-8
SKULL
AP / PA LATERAL TOWNES MASTOID
MASTOID
LATERAL
TEMPORO-
MANDIBULAR
JOINT
SELLA
TURCICA
AP
SELLA
TURCICA
LATERAL
FACIAL
AP / PA LATERAL WA TERS
ZYGOMA
ARCH
OPTIC
FORAMINA
MANDIBLE
LATERAL
STENVERS LAW’S
UPPER TRUNK
CERVICAL
AP
CERVICAL
LATERAL
THORACIC
AP
THORACIC
LATERAL
THORACIC
SWIMMER
SCAPULA
LATERAL
SHOULDER CLAVICLE
LOWER TRUNK
LUMBAR
AP
LUMBAR
LATERAL
PELVIS
AP
SACRUM
AP
SACRUM
LATERAL
ABDOMEN
AP
ABDOMEN
LATERAL
PELVI-
METRY
CHEST
AP / PA LATERAL 60” CART
UPPER
RIBS
LOWER
RIBS
STERNUM
STERNUM
LATERAL
LORDOTIC
EXTREM BUCKY
HIP AP HIP FROG FEMUR
KNEE
AP
KNEE
LATERAL
KNEE
AXIAL
HUMERUS
HUMERUS
TRANS-
THORACIC
EXTREM TBL TOP
HAND WRIST FOREARM ELBOW FOOT ANKLE TIBIA KNEE
SPECIAL
TOMO AUX
CHANGER
1
CHANGER
2
USER-1 USER-2 USER-3 CONTRAST
SUB-MENU OF
ANATOMICAL VIEWS
S
U
B
-
M
E
N
U
O
F
EXTREM TBL TOP
View-1 View-2 View-3 View-4 View-5 View-6 View-7 View-8
HAND
PA LATERAL OBLIQUE FINGERS -- -- -- --
WRIST
PA LATERAL OBLIQUE -- -- -- -- --
FOREARM
PA LATERAL OBLIQUE -- -- -- -- --
ELBOW
PA LATERAL AXIAL -- -- -- -- --
FOOT
PA LATERAL OBLIQUE TOES -- -- -- --
ANKLE
PA LATERAL OBLIQUE -- -- -- -- --
TIBIA
PA LATERAL OBLIQUE -- -- -- -- --
KNEE
PA LATERAL AXIAL -- -- -- -- --
SUB-MENU OF
ANATOMICAL VIEWS
S
U
B
-
M
E
N
U
O
F
SPECIAL
View-1 View-2 View-3 View-4 View-5 View-6 View-7 View-8
CONTRAST
GALL
BLADDER
STOMACH
AP
STOMACH
LATERAL
COLON
AIR
CONTRAST
IVP ESOPH 40 ESOPH 72
