HF Series Generators -- RAD Console
Operation
OM- 0279R1
30
3.6 HEAT UNITS
This X-ray Generator is equipped with a Heat Unit Calculator. During
exposures, the Heat Units are calculated and totalled.
To view the remaining Heat Units, press the “On” push-button. The kVp Display
shows the percentage of Heat Units that remain preceded by the letter “H”. For
example, a display of “H75” would indicate that 75% of Heat Units capacity of
the X-ray Tube remains. “H -- -- ” indicates that all the capacity remains. The kVp
Display reverts to its normal function after releasing the “On” push-button.
3.7 EXPOSURE COUNTERS
The operator can read the number of exposures made by the Generator, as
indicated below:
RAD EXPOSURES
IN TUBE-1
Press and hold and press once
RAD EXPOSURES
IN TUBE-2
Press and hold and press once
The number of exposures is shown on the kVp and mAs Displays, up to a
maximum of 999,999 exposures.
= 123.456 exposures
kV mAs
