SERVICE MANUAL FOR ST-150(F)
32/47 SeeTech
3.11. SMPS
Loosen 3 screws of bottom.
Remove SMPS cover.
Disconnect cables on SMPS board.
Remove 4 screws and then remove
SMPS board.
