SERVICE MANUAL FOR ST-150(F)
44/47 SeeTech
7. SEPCIFICATION
Counterfeit
Detection
CIS, IR, MG, UV, TDS(Thickness)
Pocket
Capacity
(New/Old)
Hopper
300/200 Notes
Currency
Maximum 10 currencies
Reject Pocket
100/70 Notes
High Speed
Value
Counting
Count Only
1500 notes/min
Stacker
300/200 Notes
Value
1500 notes/min
Dimensions
300(W) x 321(D) x 310(H) mm
Fitness(ST-150F)
1000 notes/min
Weight
Net: 13.9 Kg, Gross: 15.7 Kg
Serial(option)
800 notes/min
Power Supply
100 ~ 240V AC, 50/60 Hz
Fitness
Stain, Limpness, Dog-ear, Tears,
Hole, Fold, Multilations, Repairs,
Composed, De-inked, etc.
Globalization
Multi Languages support
Communication
Channel
LAN, USD, RS232C
(External Display, Thermal Printer)
User
Interface
TFT color LCD (4.3 inch), Audio
Upgrade
LAN, USB
8. DIAGRAM
CONNECTION FOR RS232C CABLE
ST-150(F) HOST SIDE(9P)
(F.G) 1
(TXD) 2
(RXD) 3
(S.G) 4
(F.G) 1
(RXD) 2
(TXD) 3
(S.G) 5
