Seg WIC1-W3 User Manual

Technical Manual WIC1 SEG Electronics GmbH
DOK-TD-WIC1E, Rev. M 57
8.4 Commissioning form
List of adjustments for WIC1
Project: Order No.:
Functional group: Location: Component Identification:
Relay Function: Date:
Parameter Setting
Function
Unit
Default
Setting
Actual
Setting
CT Type
W2
IS
Rated CT current
A
16
Char
Trip characteristic
DEFT
I>
Pickup value for DMT characteristic or start val-
ue of the IMT characteristic
x IS
0.9
tI>
Tripping time for DMT characteristic
s
0.04
a
Multiplier for IMT characteristic
s
--
I>>
Pickup value for short-circuit element
x IS
1
tI>>
Tripping time for short-circuit element
s
0.04
IE>*
Pickup value for earth fault element (only type
E)
x IS
0.2
tIE>*
Tripping time for earth fault element
s
0.1
Signature Checker: Signature customer:
*=Option
