4 ASSY COINCHUTE TOWER (FRI-0300) (D-2/2)
ITEM NO. PART NO. DESCRIPTION NOTE
1 FRI-0350 SW UNIT
2 SPG-0301 COIN CHUTE TOWER
3 DRT-0301 COIN METER BRKT
4 DP-1167 TNG LKG
5 253-5366 CASH BOX
6 421-6591-01 STICKER COIN METER
7 421-7501-02 STICKER 6.3V 0.15A
8 DYN-0303X STICKER COIN ENTRY
9 DYN-0305 TOWER BRKT
10 105-5202 HOLE COVER
11 SPG-0302 WIRE BOX
12 SPG-0303 WIRE BOX LID
13 440-WS0002XEG STICKER W POWER OFF ENG
101 220-5482-91-~ ASSY COIN CHUTE 2DOOR ~
220-5237-92-~ ASSY COIN CHUTE 2DOOR ~
102 220-5643-01 MAG CNTR DC5V 6P WH MZ-674-D04
103 220-5643-02 MAG CNTR DC5V 6P YE MZ-674-D05
104 220-5574 CAM LOCK W/KEYS
105 220-5575 CAM LOCK MASTER W/O KEY
106 280-5009-01 CORD CLAMP 21
107 280-5275-SR10 CORD CLAMP SR10
108 601-0460 PLASTIC TIE BELT 100 MM
109 310-5029-F20 SUMITUBE F F 20MM
110 601-6231-C045 EDGING NEW TYPE
201 000-P00412-W M SCR PH W/FS M4 X 12
202 000-T00408-0B M SCR TH BLK M4 X 8
203 010-P00408-F S-TITE SCR PH W/F M4 X 8
301 600-6373-50 WIRE HARN COIN LEFT
302 600-6373-51 WIRE HARN COIN RIGHT
303 600-7076-072 WIRE HARN EARTH EXT COIN CHUTE
304 600-7076-073 WIRE HARN EARTH COIN CHUTE
305 600-6972-0130 WIRE HARN EARTH ID5 0130MM
306 FRI-61048 WIRE HARN EXT WOOFER VR L B
307 FRI-61049 WIRE HARN EXT WOOFER VR R B
308 FRI-61050 WIRE HARN EXT COIN L B
309 FRI-61051 WIRE HARN EXT COIN R B
310 FRI-61052 WIRE HARN EXT COIN L C
311 FRI-61053 WIRE HARN EXT COIN R C
312 FRI-61054 WIRE HARN EXT WOOFER VR L C
313 FRI-61055 WIRE HARN EXT WOOFER VR R C
314 FRI-61056 WIRE HARN EXT COIN L D
315 FRI-61057 WIRE HARN EXT COIN R D
316 FRI-61058 WIRE HARN EXT COIN L E
317 FRI-61059 WIRE HARN EXT COIN R E
