18 - 3 ERROR DISPLAY (DRIVE CONTROL BOARD)
If an irregularity occurs in the Drive Control Board, etc., the ERROR message is shown on the
screen and the 7-SEG display on the Drive Control BD. Take countermeasures in the manner
corresponding to the ERROR message. Note that even at the time of error occurrence, game
play is possible without Steering Wheel reaction.
Among the ERROR display as per Table 18.3, each of Er 01, 02, 20 and 22 is displayed before
the Advertise mode is displayed if an irregularity is found during initialization setting
movements when power is turned on and at the time the Test Mode is finished.
From among error displays as per Table 18.3, Er 23, 24, and 25 indicate On-Board 7-SEG error
display when an irregularity is found during game and ADVERTISE mode. If an irregularity is
found during game, game play can be continued without Steering Wheel reaction.
 Be careful so as not to damage wirings. Damaged wiring can cause electric
shock and short circuit hazards.
 Do not touch undesignated places. Touching places not specified can cause
electric shock and short circuit hazards.
Table 18. 3 ERROR DISPLAY
ERROR
ROM ERROR
RAM ERROR
Initialization
setting irregular-
ity of motor
Steering Wheel's
centering error
ERROR of the
Encoder incorpo-
rated in the
motor.
Overcurrent
ERROR
Overheat
Overload
CAUSE/COUNTERMEASURES
Malfunctioning of Drive Control Board.
Replace Drive Control Board.
Irregularity during initialization setting movement.
Finish initialization setting movement by turning
power off and then on. Note that when ERROR is
displayed,the malfunctioning relates to the Motor
System (Motor, Drive Control BD which controls the
Motor, Drive BD., wirings in between, etc.)
Malfunctioning during initial setting movement.
Finish initialization setting movement by turning
power off and then on. Note that when ERROR is
displayed, the malfunctioning relates to the Steering
Wheel Volume system.
Malfunctioning which occurs during operation.
First turn the power off and after 10 min., turn it back
on again. Note that when this Error is displayed, the
malfunctioning relates to the Motor System.
7-SEG display on
Drive Control BD.
Er 01
Er 02
Er 20
Er 22
Er 23
Er 24
Er 25
