Sega F355 Challenge User Manual

132
www.seuservice.com
ITEM NO. PART NO. DESCRIPTION NOTE
1 FRI-4601 WOODEN BASE ELEC
2 838-13578 PWR AMP 2CH & MIXER
3 838-11651-01 LOWPASS AMP W/LARGE HEAT SINK
4 838-12912-01 SERVO MOTOR DRIVE BD NEW
5 838-13843 DRIVE BD FRI
6 838-11856-01-UL CONNECT BD W/FUSE & COVER UL
7 839-1148 4A DC SSR BD NH4P
8 839-1151 CAPACITOR BD
9 421-6595-11 STICKER 7A
101 560-5434-V XFMR 100-120V 100V7.5A AC 100V AREA
560-5435-V XFMR 220-240V 100V7.5A CE AC 220 ~ 240V AREA
102 560-5405-V XFMR 100V 14V6.3A
103 211-5305 C JMPR SCKT (IMSA-9206H-GF)
104 514-5036-7000 FUSE 6.4 X 30 7000MA 125V
105 280-0419 HARNESS LUG
106 280-5009-01 CORD CLAMP 21
107 601-0460 PLASTIC TIE BELT 100 MM
108 270-5117 FERRITE CORE TDK ZCAT3035-1330
201 011-T00325 TAP SCR TH 3 X 25
202 011-T00316 TAP SCR TH 3 X 16
203 011-T03512 TAP SCR TH 3.5 X 12
204 011-F00310 TAP SCR FH 3 X 10
205 000-P00512-W M SCR PH W/FS M5 X 12
206 000-P00412-W M SCR PH W/FS M4 X 12
301 FRI-61001 WIRE HARN CONN BD IN
302 FRI-61002 WIRE HARN CONN BD OUT A
303 FRI-61003 WIRE HARN CONN BD B
304 FRI-61004 WIRE HARN M.DRIVE BD AC100V
305 FRI-61005 WIRE HARN AC14V
306 FRI-61006 WIRE HARN AMP SPEAKER
307 FRI-61007 WIRE HARN AMP AUDIO
308 FRI-61008 WIRE HARN AMP VR
309 FRI-61009 WIRE HARN AMP TO AMP
310 FRI-61010 WIRE HARN DRIVE BD
311 FRI-61011 WIRE HARN SSR BD SIG
312 FRI-61012 WIRE HARN M.DRIVE BD ENCODER
313 FRI-61013 WIRE HARN TX & RX
314 FRI-61014 WIRE HARN DRIVE BD DC IN
25 ASSY ELEC BASE (FRI-4600) (D-2/2)
