74www.seuservice.com
Move the Seat to the rearmost portion and apply spray greasing to the portion shown at the right
once every 3 months by using NOK KLUBER L60 or GREASE MATE SEGA PART No.
090-0066.
After greasing, move the Seat a few times forward and backward so as to allow the grease to be
applied all over uniformly. Be sure to wipe grease which attaches to the surfaces of the
PROTECT RUBBER on the Seat Rail, or any excess grease.
FIG. 16
CLEANING THE CABINET SURFACES
When the cabinet surfaces are badly soiled, remove stains with a soft cloth dipped in water or
diluted (with water) chemical detergent and squeezed dry. To avoid damaging surface finish, do
not use such solvents as thinner, benzine, etc. other than ethyl alcohol, or abrasives, bleaching
agent and chemical dustcloth.
SEAT (Greasing to Seat Rail Portion)
To Next Page
