CONTROL UNIT
10
10-5 REPLACING THE STROBULB SWITCH
• Alwaysremovepower,switchoffthemachineandremovethepowercable
beforeattemptinganywork.
Refer to “10-3 Disassembling the Poltergust Controller” to disassemble the Poltergust controller.
1
Remove power from the machine and disconnect the mains power connector.
2
Refer to “10-3 Disassembling the Poltergust Controller” to disassemble the Poltergust controller.
3
Remove the fast on terminals (2) and screws (2) and remove the Strobulb switch.
4
Reverse the directions to replace the unit, paying special attention to the location of the trigger switch’s fast
on terminal connections.
