Seiko V172A - Disassembling and Reassembling of Solar Cell; Date Dial Group

• DisassemblingandReassemblingofSOLARCELL
* Do not apply excessive force to the SOLAR CELL.
<Disassembling>
As there are 2 connection parts of the HOLDING RING FOR
DIAL,release them side by side.
<Assembling>
Set the SOLAR CELL to 3 guide posts, and assemble it to the
HOLDING RING FOR DIAL by expanding the hooking portion
as shown in the illustlation.
⑧ DATE DIAL GUARD
• Lubrication
Lubricate the DATE JUMPER and the tip of the DATE DIAL.
AO-3
TECHNICAL GUIDE
Cal. V172A/V174A
12/25
