Sekonic C-800 Startup Guide

★
If Dark Calibration Position Confirmation screen appears, set the Light Selection
Ring
❷
to Dark Calibration position and perform calibration again.
*
If "Please set Light Selection Ring for
dark calibration" is displayed, set the Light
Selection Ring
❷
to the dark calibration
position to start calibration.
*
When taking measurements, set the Light
Selection Ring
❷
to the range L (icon at the
middle) for ALL ambient light.
For flash light, set the ring to "H" (icon at the
top) high-power (brighter than 640lx·s) flash
or "L" (icon at the middle) for low-power flash
(lower than 640lx·s).
Dark Calibration Position
Confirmation Screen
NOTE
Dark calibration is performed when there is a big change in temperature
between turning power OFF and ON.
Except the cases above, dark calibration after power ON is skipped.
5. Measuring Mode and Display Mode
You can change screens after turning the power on as follows. Changes
from the Measuring screen to each screen.
★
Pressing Menu Button
❻
shifts to the Display Mode Selection screen.
Please set Light Selection
Ring for dark calibration.
[
Measuring Mode
Selection
Screen
]
[
Display Mode
Selection Screen
]
1 3
64
97
2
5
8
󱧃󱧁 󱧂
[Measuring
Screen
(Text Mode)
]
w ww. . com
information@itm.com1.800.561.8187

Sekonic C-800 Specifications

General

Dimensions (WxDxH)	73 x 183 x 27 mm
Interface	USB 2.0
USB powered	Yes

Weight and Dimensions

Weight	230 g
