Figure 2.7 SEL Cable C285: SEL-3031 to DTE Device (SEL Relays)
Figure 2.8 SEL Cable C782/C387: SEL-3031
to SEL Communications
Processor
USB Interface
The SEL-3031 uses a standard USB Type-B interface for the management port. The
USB interface is used for settings management, initial radio installation, and reporting
data from long-term radio statistics. The management port may be used while the
SEL-3031 is in service without disrupting the radio communications. To use this
interface, plug a USB Type-B cable into the radio and plug the other end into your PC.
This will automatically prompt your PC to install a USB-to-serial driver that creates a
virtual serial port. The virtual serial port needs to be set to 9600 bps, 8 data bits, 1 stop
SEL-3031
9-Pin Male
Subminiature "D" Connector
No IRIG
9-Pin Male
Subminiature "D" Connector
2
3
5
7
8
2
3
5
7
8
RXD
TXD
GND
RTS
CTS
Pin
Func.
Pin # Pin #
DTE Device
NOTE: For best results, limit the cable length to 15 meters (50 ft)
ORANGE
RED
BLUE/SHIELD
GREEN
WHITE
SEL-3031
9-Pin Male
Subminiature "D" Connector
With IRIG
9-Pin Male
Subminiature "D" Connector
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Pin # Pin #
NOTE: For best results, limit the cable length to 15 meters (50 ft)
CAUTION: You must turn off the +5 V on Pin 1 of the SEL-3031 when
connecting to a communications processor.
SEL Communications Processor
