Sel SEL-3031 - List of Figures

Date Code 20091009 SEL-3031 Instruction Manual
List of Figures
Figure 1.1 Product Overview .............................................................................1.1
Figure 1.2 SEL-3031 Dimensions......................................................................1.4
Figure 1.3 SEL-3031 Rack Mount (Front and Rear) .........................................1.5
Figure 1.4 SEL-3031 Wall Mount (Front and Rear) ..........................................1.6
Figure 2.1 Fresnel Zone .....................................................................................2.2
Figure 2.2 Antenna Polarization.........................................................................2.5
Figure 2.3 Wall-Mount and Rack-Mount Rear Connections .............................2.7
Figure 2.4 Two-Wire EIA-485 Connections ....................................................2.12
Figure 2.5 EIA-232 and EIA-485 DB-9 Connector Pin Numbers...................2.13
Figure 2.6 SEL Cable C245A: SEL-3031 to Computer...................................2.14
Figure 2.7 SEL Cable C285: SEL-3031 to DTE Device (SEL Relays)...........2.15
Figure 2.8 SEL Cable C782/C387: SEL-3031 to SEL Communications
Processor....................................................................................2.15
Figure 2.9 USB Interface .................................................................................2.16
Figure 3.1 SEL M
IRRORED BITS Connection Example......................................3.1
Figure 3.2 SEL-3031 Port Settings for MIRRORED BITS Connection ................3.2
Figure 3.3 SEL-351 Port Settings for MIRRORED BITS Connection ..................3.3
Figure 3.4 SEL-451 Port Settings for MIRRORED BITS Connection ..................3.4
Figure 3.5 SEL-2505 DIP Switch Settings for MIRRORED BITS Connection ....3.5
Figure 3.6 TAR ROKA Command From an SEL-351.......................................3.6
Figure 3.7 SEL-3031 Linking Information Processors to Relays......................3.6
Figure 3.8 SEL-3031 Port 1 Settings for Fast Messaging..................................3.7
Figure 3.9 SEL-351 Port Settings for Fast Messaging.......................................3.8
Figure 3.10 Example AUTO Command Output...................................................3.9
Figure 4.1 Communications Menu.....................................................................4.2
Figure 4.2 Serial Port Communications Parameters ..........................................4.3
Figure 4.3 Terminal Window Menu ...................................................................4.4
Figure 4.4 Device Response to ID Command....................................................4.4
Figure 4.5 Selection of Drivers ..........................................................................4.7
Figure 4.6 Update Part Number .........................................................................4.8
Figure 4.7 New Setting Screen...........................................................................4.8
Figure 4.8 Status Screen...................................................................................4.10
Figure 4.9 Radio Strength and Channel Availability .......................................4.11
Figure 4.10 RAD Command Response..............................................................4.21
Figure 4.11 Device Response to the STATUS Command..................................4.24
Figure 5.1 Example RAD Command.................................................................5.2
Figure 5.2 RBAD Generation.............................................................................5.4
Figure B.1 SEL-3044 Encryption Card .............................................................B.1
Figure B.2 In-Band Data Packet Format............................................................B.4
Figure B.3 Operation of the AES Encryption Function.....................................B.5
Figure B.4 Encryption Card Location................................................................B.7
