Section 4
Settings and Commands
PC Software
ACSELERATOR QuickSet
®
SEL-5030 Software is a powerful settings and HMI tool
that aids in setting, applying, and using the SEL-3031 and other SEL devices. This
section describes how to get started with your SEL-3031 and
ACSELERATOR QuickSet.
Setup
Follow the steps outlined in Section 2: Installation to prepare the SEL-3031 for use.
Perform the following steps to initiate communications:
Step 1. Apply power to the SEL-3031.
Step 2. Connect a USB Type-B cable (SEL-C664) between the management
port of the SEL-3031 and the PC.
Step 3. Follow the on screen instructions and install the USB driver if not
already installed.
Step 4. Start
ACSELERATOR QuickSet software.
Ta b le 4.1 ACSELERATOR QuickSet SEL-5030 Software
Terminal Provides a direct connection to the SEL device. Use this com-
munications method to interface directly with the device.
Rules-Based Settings
Editor
Provides online or offline device settings that include
interdependency checks. Use this feature to create and
manage settings for multiple devices in a database.
Settings Database
Management
Provides a database to manage multiple device settings.
Help Provides general
ACSELERATOR QuickSet and device-spe-
cific
ACSELERATOR QuickSet context help.
