3
FRENCH
Contenu de la boite
Corps de l’Antenne
Equerre de Support
Support Principal
Support de Fixation A
Support de Fixation B
Clé à Boulon
Boussole
A1
B1
B2
B3
B4
C1
C2
Ancrage Hexagonal M6x18 SEMS2 (×3)
Ancrage Hexagonal M6x50 SEMS2 (×1)
Vis à Tête Bombée à Collet Carré M6x50 (×3)
Vis à Tête Bombée à Collet Carré M6x75 (×4)
Ecrou à Collet carré M6 (×7)
S1
S2
S3
S4
N1
A1
B1
B2
B3
B4
C2C1
S3 S4 N1
S1 S2
