3
ENGLISH
Box Content
Antenna
Angle Bracket
Main Support
Fix Bracket A
Fix Bracket B (×2)
Spanner
Compass
A1
B1
B2
B3
B4
C1
C2
Screw M6x18 SEMS2 (×3)
Screw M6x50 SEMS2 (×1)
Round Head Square Neck Bolt M6x50 (×3)
Round Head Square Neck Bolt M6x75 (×4)
Flanged Nut M6 (×7)
S1
S2
S3
S4
N1
A1
B1
B2
B3
B4
C2C1
S3 S4 N1
S1 S2
