3
ITALY
Contenuto
Antenna
Staa angolare
Supporto principale
Staa di posizione B
Staa di posizione A
Chiave
Bussola
A1
B1
B2
B3
B4
C1
C2
Vite M6x18 SEMS2 (× 3)
Vite M6x50 SEMS2 (× 1)
Bullone a testa tonda larga con quadro sottotesta
M6x50 (× 3)
Bullone a testa tonda larga con quadro sottotesta
M6x75 (× 4)
Dado angiato M6 (× 7)
S1
S2
S3
S4
N1
A1
B1
B2
B3
B4
C2C1
S3 S4 N1
S1 S2
