SELFSAT IP series User Manual

4
A1
B1
B2
B3
B4
B5 B6
C4C3C2
C1
S1 S3S2 S4 S5 N1S6
C5 E1
Antenna
Angle Bracket
Main Support
Window Bracket A
Window Bracket B
Fix Bracket B
Fix Bracket A
Cable gland
PoE injector
RF connector water-proof cap (
×
2)
A1
B1
B2
B3
B4
B5
B6
C1
C2
C3
Spanner
Compass
Rubber (
×
4)
Screw M4X10 SEMS2 (
×
4)
Screw M6x18 SEMS2 (
×
3)
Screw M6X50 SEMS2
Round Head Square Neck Bolt M6x30
Round Head Square Neck Bolt M6x50 (
×
3)
U-Bolt M6x85 (
×
2)
Flanged Nut M6 (
×
7)
C4
C5
E1
S1
S2
S3
S4
S5
S6
N1
Box Content
(Integrated in the backside of the antenna)
(Integrated in the backside of the antenna)
