SELFSAT IP series User Manual

6
Step 2: Check Information
In order to install antenna, you need to nd skew, elevation and azimuth angle by referring the table on the
back of the manual. If you can’t nd your location, please refer to the information of the nearest area from
your location. This manual will show you the installation example to receive ASTRA1 satellite in Brest region
of France. The angle information for Brest region is Skew : -19.7, El : 30, Az : 149.6
2) Wall Mounting Type
2
4
Depending on the choice of installation position for the SELFSAT>IP series, you can then decide on
the mounting type, all parts are included.
Step 3: Installation Choice
1) Table Stand Type (on a Horizontal Plain)
12
3
S2
S5
S2
N1
B1
B5
B1
A1
S1
S2
S4
N1
12
3
S2
S5
S5
N1
S2
N1
B1
B2
B6
B2
A1
S2
S3
