2-2. Name of parts
Parts of main unit
Parts of controller
• Front
• Back
OnLED Indicator
Power S/W
USB port
MODE LED
(O: In-motion mode /On: Stationary mode)
Satellite LEDs
TRACKING LED
LOCK LED
MODE button
Arrow buttons
SET button
BlinkingO
Receiver cable to Receiver
Controller cable to Main unit
Power port
Antenna
Mounting plate
to Controller ("ANT" port)
