4
2-2. Nomi dei pezzi
Parti dell’unità principale
Parti del controllore
• Davanti
• Ndietrro
OnIndicatore LED
Alim. S/W
Porta USB
LED MODO
(O: In-motion mode /On: Stationary mode)
LED satellites
LED TRACCIAMENTO
LED blocco Tasto MODO
Tasti freccia
Tasto SET
LampeggianO
Ricevitore cavo al Ricevitore
Cavo controller all’un.. princ
Porta alim
Antenna
Piastra di
montaggio
al Controll. (porta "ANT")
