SEMTOM ST-900 - Batch Mode; Counting Speed Setting

第 11 页 共 24 页
the notes from the stacker.
4）Batch mode
By pressing “BATCH” to turn on/off the Batch function, then press “0-9” numeric key to set the batch
number(range from 0-999)
In the batch mode, press “1238” numeric keys then press “RESTART”, the user can check the total
counting number since the machine left from the factory
Notes: When the machine is stop in the mode of BATCH, there is no notes in the hopper and the
count number is the same with the batch number, user should remove the notes from the stacker in
case the last notes will be jammed in the machine.
5）Counting speed setting
The user can choose the counting speed among “800, 1100, 1400, 1600pcs/min” by pressing “SPEED”
key
