5S Motorcycle Bluetooth Communication System | 12
2 INSTALLING THE HEADSET ON YOUR HELMET
2.3.2 Installing the Wired Microphone
If you have a full face helmet, you can use the wired microphone.
1. Attach the included hook and loop fastener for wired microphone to
the inside of the helmet’s chin guard.
2. Attach the wired microphone to the hook and loop fastener for wired
microphone.
3. Align the arrows on the microphone and speaker cables and insert
the microphone cable into the speaker cable.
4. Insert the speaker connector into the speaker port to connect it to
the main unit.
