- 18 _EN- SL320005700 Ed.00 - 04-2011
7.9.1. Cleaning the Granitore 1/1FF condenser
The safety guards must be removed by means of a suitable screwdriver.
Remove the rear guard after taking out the screws securing it to the frame (the
screws are positioned on the left and right sides).
After removing the guard, use a dry brush to remove the dust that has built up
over time with use.
Fig.45
7.9. Cleaning the condenser
The condenser may be cleaned solely by a specialized techni-
cian, who must organize all of the operational sequences and
use suitable equipment, in strict compliance with the applica-
ble regulations currently in force.
Periodically clean the condenser situated inside the machine.
Warning: Removing safety guards will expose some sharp sur-
faces of the machine.
A dirty condenser will impair machine performance.
To access the condenser remove the safety guards.
It is forbidden to use the machine when even only one panel
(front, rear or side) is not set properly in place. It is prohibited
for the operator to clean the condenser.
Once the condenser has been thoroughly cleaned, fi t all the safety guards back
in position.
Fig.46
After removing the guard, use a dry brush to remove the dust that has built up
over time with use.
7.9.2.
Cleaning Granitore 2/2 FF - 3/3 FF cond.
To remove the safety guard panel, proceed as follows:
- Lift and completely remove the upper part of the side guard;
- Unattach the fl aps pushing them simultaneously and pulling the panel as
shown in the fi gure;
Fig.44
Fig.47
Fig.48
