SL320005700 Ed.00 - 04-2011 - 17 _EN-
7.7. Cleaning the drip tray
The drip tray should be emptied and cleaned daily.
Note: all of the drip trays present in the machine should be
cleaned.
The drip tray should be emptied and cleaned every time the red
fl oat installed in the grid rises into view.
Holding the drainage hose fi rmly, lift the tray with the grid on top of it and pull
it out.
Wash the tray and grid separately with lukewarm water.
Dry all of the components.
Reposition the grid on top of the tray.
Position the drainage hose in the opening provided.
Fit the tray back in place and press down to secure it to the machine.
7.8. Lighted lid
Maintenance of the lighted lid must be entrusted solely to a
specialized technician, who must organize all of the operation-
al sequences and use suitable equipment, in strict compliance
with the applicable regulations currently in force.
The operator is forbidden to disassemble any lid component.
Clean the lid contacts using a wet cloth, and dry carefully. Always
carry out this operation when the machine is off.
Remove the bulb “U” from the socket “T” , and replace it with a new one.
Refi t the lid, and tighten both screws.
7.8.1. Bulb replacement
The bulb must be replaced only when the main switch is in posi-
tion -0- and power cord is unplugged.
remove the protection caps; undo both screws to split the lighted lid sections;
use a proper screwdriver for this operation.
Warning: during the cleaning operations, take care not to dam-
age (bend, break, etc.) the contacts; any damage might cause a
bad functioning of the lid, which is not under warranty.
Fig.41
Fig.43
Fig.42
