Seneca Z-SG - Weight, Output, and Threshold Registers

USER MANUAL – Z-SG
20
Weight
32 bit
"
0% Analog
Out
Weight
Net Weight that will generate 0% of the
analog out
Floating
Point
32 bit
R/W Flash
"0.00
0"
40052-
40053
51-52
Weight
Threshold
Threshold for Digital Output Threshold
mode
Floating
Point
32 bit
R/W Flash
"5000
.000"
40054-
40055
53-54
Delta
Weight
Delta Weight for the "Stable" Weight
condition
Floating
Point
32 bit
R/W Flash
"1.00
0"
40056
55-56
Delta time
Delta Time for the "Stable" Weight
condition.
The value must be multipled x 100ms (for
example value of 10 = 1 second)
unsigned
16 bit
R/W Flash
100
ms
40058
57
Resolution
/ Out NO
NC /
Switch
Condition
Bit[15] Full Resolution:
1 = Full resolution
0 = Resolution from Bit [14...8]
Bit[14..8] Resolution:
Must be stored the Resolution
Value/1000 (example: for 30000 points
write 30)
Bit[7] NO/NC:
0 = Output is normally Open
1 = Output is normally Close
Bit[6..0] Digital Output Switch
condition:
0=gross weight is greater than load
cell end scale
1=weight is stable and net weight is
greater than Threshold
2=weight is stable
3 = Output is controlled from Modbus
Register "Status" (only Z-SG-L)
unsigned
16 bit
R/W Flash
0
40059
58
Sampling
Frequency
/
Rejection
See Sampling Frequency / Rejection
Register
value
Sampling
Frequency
[Hz]
50
Hz
Rejec
tion
60 Hz
Rejection
unsigned
16 bit
R/W Flash
0x0052
40060
59
