Audio
220
Audio
Which microphones can I use with my bodypack transmit-
ter?
• EW-D SK: „Connecting a microphone to the bodypack
transmitter“
• EW-DX SK (3-PIN): „Connecting a microphone to the
bodypack transmitter“
Which microphone modules can I use with my handheld
transmitter?
• EW-D SKM-S: „Replacing the microphone module“
• EW-DX SKM(-S): „Replacing the microphone module“
What exactly do the “Gain” and “AF Out” settings do?
• Gain: level of the audio signal coming from the transmitter
(„GAIN menu item“)
• AF Out: level of the audio signal coming out of the receiver
(„AF OUT menu item“)
How do I adjust the settings so that my wireless link has the
same volume as my guitar cable?
• EW-D: Configure unity gain settings under the menu items
GAIN (volume that reaches the receiver from the guitar
through the bodypack transmitter – „GAIN menu item“) and
AF OUT (volume output from the receiver to the guitar am-
plifier – „AF OUT menu item“).
Possible unity gain settings (depending on the level of the in-
coming signal):
▷ AF Out 18 dB | Gain 27 dB
▷ AF Out 12 dB | Gain 33 dB
▷ AF Out 6 dB | Gain 39 dB
