Using the operating menu
19
Display Function of the menu item
Main menu “Menu”
Sensitivity Adjusts the input sensitivity
Easy Setup Deactivates the RF signal and activates Easy Setup Sync (see page 15)
Mode Selects mono or stereo operation
Frequency Preset Changes the frequency bank and the channel
Name Enters the transmitter name
AutoLock Activates/deactivates the automatic lock mode
Advanced Calls up the extended menu “Advanced Menu”
Exit Exits the operating menu and returns to the standard display
Extended menu “Advanced Menu”
Tune Sets the transmission frequencies for the frequency banks “U1” to
“U6”
Special function: Sets a channel and a transmission frequency for the
frequency banks “U1” to “U6”:
왘 Select this menu item and call it up by pressing the jog dial until
the channel selection appears.
Sync Settings Adjusts the receiver parameters to be transferred to the receiver and
activates/deactivates the transfer (see table on page 15)
RF Power Adjusts the transmission power
Warnings Calls up the submenu “Warnings”
LCD Contrast Adjusts the contrast of the display panel
Reset Resets the transmitter
IP-Address Adjusts the IP address of the transmitter
Software Revision Displays the current software revision
Exit Exits the extended menu “Advanced Menu” and returns to the main
menu
Submenu “Warnings”
Activates/deactivates warnings (color change and warning messages):
AF Peak Audio overmodulation
RF Mute RF signal is deactivated
Exit Exits the submenu “Warnings” and returns to the extended menu
“Advanced Menu”
