The SR 2000 IEM and SR 2050 IEM transmitters
4
The SR 2000 IEM and SR 2050 IEM transmitters
With the SR 2000 IEM and SR 2050 IEM 2-channel/stereo monitoring transmitters, musi-
cians, video and sound amateurs, reporters/broadcasters, etc. can directly monitor the
received sound signals without troublesome cables or monitor speakers being required. In
addition, the transmitters can also be used for any application where talkback signals are to
be transmitted.
Features of the SR 2000 IEM and SR 2050 IEM transmitters:
• Optimized PLL synthesizer and microprocessor technology
•Stereo/mono selection
• HDX noise reduction system
• Switching bandwidth of up to 75 MHz
• Safe configuration of a multi-channel system using the WSM
• Easy setup of a multi-channel system using the Easy Setup Sync function
The frequency bank system
The transmitters are available in 5 UHF frequency ranges with up to 3,000 transmission
frequencies per frequency range:
Each frequency range (Aw–Dw, Gw, GBw) offers 26 frequency banks with up to 32 channels
each:
Each of the channels in the frequency banks “1” to “20” has been factory-preset to a fixed
transmission frequency (frequency preset). The factory-preset frequencies within one
frequency bank are intermodulation-free. These frequencies cannot be changed.
500 600 700 800
Range
Gw:
558 – 626
Range Bw:
626 – 698
Range
Cw:
718 – 790
Range Dw:
790 – 865
516 – 558
Range
Aw:
GBw
:
606 – 678
Range
Frequency bank 1... 20
Frequency bank U1 ... U6
Channel 32 – frequency preset
Channel 1 – frequency preset
Channel 2 – frequency preset
Channel 32 – freely selectable frequency
Channel 1 – freely selectable frequency
Channel 2 – freely selectable frequency
