Page 55
.
Glossary of Symbols
Symbol Name Description of Symbol
Equipoten-
tiality
Equipotential Terminal (ground)
ON
(SDM rear
button)
Monitor ON
OFF
(SDM rear
button)
Monitor OFF
I/O
Multipurpose
Port
Nurse Call + Analog Output
Nurse Call
Nurse Call (integrated into
Multipurpose Port)
RS-232
Serial Data Port (RS-232)
LAN
LAN
Local Area Network Port
Defibrillation
Proof
Type BF
Degree of protection against
electrical shock:
Defibrillation-proof, Type BF
applied part
Fuse
Indicates fuse type
IPX1
Type IPX1
Degree of protection against
harmful ingress of water:
Drip-proof equipment
Symbol Name Description of Symbol
CE Label
Indicates that the product
complies with the requirements
of the Medical Device Directive
93/42/EEC June 1993.
If applicable, the 4-digit Notified
Body number is added near or
below the CE symbol.
Caution
Refer to accompanying documents
for further details.
UL Label
Declaration of conformity of the
equipment
WEEE
Disposal
European consumers are obliged
by law to dispose Waste Electrical
and Electronic Equipment (WEEE)
according to the WEEE Directive
2002/96/EC:
1. All electrical and electronic
waste must be stored, collected,
treated, recycled and disposed of
separately from other waste.
2. Consumers are obliged by law to
return electrical and electronic devices
at the end of their service lives to the
public collection points set up for this
purpose or point of sale. Details to
this are defined by the national law of
the respective country.
Note: By recycling materials or
other forms of utilizing old devices,
you are making an important
contribution to protecting our
environment.
