Battery Replacement
1
2
The battery icon ( ) will light when the batteries need to be replaced. No code is erased when
the old batteries are removed for replacement.
Insert 4 new alkaline batteries (not included)
Remove screw located under lock
Turn the electronic lock case to the right (clockwise),
from 12 o’clock to 2 o’clock, and remove.
Insert 4 new AA alkaline batteries.
Replace the lock case, and turn to the left to reassemble.
NOTE: Do not use rechargeable batteries or any other type of non-alkaline battery. Do not mix old
and new batteries. Do not mix alkaline and standard batteries.
Battery replacement
3
4
