2. Slide the card holder left to unlock and then carefully lift and pivot to open it. Remove the
smartcard (or dummy smartcard). Do not use force or over-bend the retainer.
Fit the smartcard or dummy smartcard
Caution! Risk of damage to the radio. The smartcard cover must be refitted
correctly to retain the radio's IP rating (mod state 4 onwards ).
1. Slide the card holder retainer left until it unlocks.
2. Slide the card holder left to unlock and then carefully lift and pivot to open it. Fit the smartcard
(or dummy smartcard). Do not use force or over-bend the retainer.
Level 1 Service Guide 13
