Sepura SC21 Series Service Guide

Smartcard
If required by your Network Operator, the radio may be fitted with a smartcard to enable access to
the network.
NOTE: Mod State 1-3 - If a smartcard is not required, the radio must be fitted
with a dummy smartcard (part no. 700-00883).
It is recommended that the smartcard (or dummy smartcard) is removed when cleaning the battery
and smartcard compartments.
Remove the smartcard or dummy smartcard
Caution! If a belt clip is fitted to the radio, lift the belt clip before attempting to
remove or fit the battery. Do not attempt to slide the battery into the battery
compartment sideways under the belt clip. This may result in damage to the
radio and the battery contacts.
Power off the radio and remove the battery. See Battery on page11.
Caution! Risk of damage to the radio. Do not attempt to remove the
smartcard cover by levering along the sealed edges with tooling.
1. Using the handle recesses, carefully lift the smart card cover (if fitted) away from the radio with
your thumb and forefinger.
12 SC21 Series hand-portable radio

Sepura SC21 Series Specifications

General

IP Rating	IP54
Operating Temperature	-20°C to +55°C
Channel Spacing	25 kHz
Ingress Protection	IP54
Channels	Up to 2000
Frequency Bands	380-430 MHz, 806-870 MHz
Battery Life	Up to 14 hours
RF Power Output	1W
TETRA Air Interface	ETSI EN 300 392-2
