SLK-R602 Series Industrial Cellular Router
Web：www.seriallink.nete‐Mail：info@seriallink.netMobilePhone：+86‐18682315199

Hardware ：
Hardware
CPU
32-bit high performance communication CPU,32bit/400MHZ
Flash/RAM
8M/64M
OS
LINUX latest version
Interface：
Interface
LAN 口 1 x 10/100M port
WAN 口 1x 10/100M WAN/LAN port
Reset
1x Reset
Serial Port(RS232)
1Xrs232(optional)
Antennas
1x 3G/4G Antenna(50Ω SMA interface )
1x WiFi or GPS antenna（option）
LED
Power-SYS-LAN-WiFi-3G/4G LED
SIM slot
Supported 1.8/3.3V SIM card
we support SIM card converter meet all size sim card
Power interface ：
Power
Default power
DC 12V/1A power adapter (US,EU etc stander option)
Input VDC
6~28V
Power Dissipation
Min: 260mA@12VDC
MAX: 500mA@12VDC
Average:320mA@12VDC
Physical property：
Physical property：
Operating
Temperature
Storage Temperature: (-30°C to 70°C)
Operating Temperature: (-40°C to 75°C)
Relative Humidity
95%
Size
L*S*H: 98m x60mm x 24mm
Weight
Net weight:400g
Packing weight: 1kg
Others：
other
Warranty
5 years
Package contains
Seriallink Router,1.5m long RJ45 Cable,12V/1A Power Adapter,Antennas
User manual( Option choose PDF),Warranty card, CERTIFICATION
