SLK-R602 Series Industrial Cellular Router
Web：www.seriallink.nete‐Mail：info@seriallink.netMobilePhone：+86‐18682315199

2.4netw orkconnection
If you are connected to a computer or a device that requires Internet access, insert the yellow cable into
any lan1-lan4 interface.
2.5c onnectthepoweradapt er
The sinolink 4G router supports 6-28v wide voltage input and USES our standard 12V/1A power adapter
by default.If you need the external power adapter can access 6-28VDC dc dc power supply and ensure
the power supply is not less than 8W.It is recommended to use 12V/1A national standard power adapter.
2.6indicat orlight description
Senor group g 4 g router is provided with the following signal indicator lights, according to "PWRS", "SYS",
"3 g / 4 g", "WIFI", "WAN", "LAN1 "
Signal strength display
Defines as follows：
LED Status Definition
PWR
OFF
No power is plugged in, or the machine is damaged
Normally on The power input is correct and the machine is energized
SYS
OFF The system did not start
Normally flash
The system is starting up
Normally on
The system is up and running
3G/4G
Normally on Not registered to 3G/4G networks
Quick flash Registered to 3G/4G networks
Slow flash Not registered to 3G/4G networks
WIFI
Normally on
SYS have ok,wifi have working
Normally flash
The WiFi client connects successfully
and has data interaction
WAN OFF
WAN port cable not inserted (generally used for broadband
line access)
Normally flash WAN port cable insertion with data interaction
Normally on WAN port cable insertion, no data interaction
LAN1 OFF
No cable is inserted at the corresponding LAN port
Normally flash The corresponding LAN port has cable insertion and data
interaction
Normally on
The corresponding LAN port has cable insertion and no
data interaction
